Key Features

• MPN: 82UG001WIN
• Model: Legion S7 16ARHA7
• Processor: AMD Ryzen 7 6800H (16M Cache, 3.2 GHz up to 4.7 GHz)
• RAM: 16GB DDR5, Storage: 1TB SSD
• Graphics: RX 6800S 8GB GDDR6

• Specification

  Processor
  Processor Brand	AMD
  Processor Model	Ryzen 7 6800H
  Processor Frequency	3.2 GHz up to 4.7 GHz
  Processor Core	8
  Processor Thread	16
  CPU Cache	L1 Cache: 512KB L2 Cache: 4MB L3 Cache: 16MB
  Chipset
  Chipset Model	AMD SoC Platform
  Display
  Display Size	16"
  Display Type	IPS
  Display Resolution	WQXGA (2560x1600)
  Touch Screen	N/A
  Refresh Rate	165Hz
  Display Features	500nits Anti-glare, 100% sRGB, 165Hz, DisplayHDR 400, Dolby Vision, FreeSync, G-SYNC, Low Blue Light, High Gaming Performance
  Memory
  RAM	16GB
  RAM Type	DDR5
  Bus Speed	4800MHz
  Total RAM Slot	2
  Max RAM Capacity	Up to 16GB
  Storage
  Storage Type	M.2 2280 PCIe 4.0x4 NVMe
  Storage Capacity	1TB SSD
  Extra M.2 Slot	One M.2 2280 PCIe® 4.0 x4 slot
  Graphics
  Graphics Model	AMD Radeon RX 6800S
  Graphics Memory	8GB
  Graphics Type	GDDR6
  Keyboard & TouchPad
  Keyboard Type	White Backlit, English (EU)
  Camera & Audio
  WebCam	FHD 1080p with E-shutter
  Speaker	Yes
  Microphone	Yes
  Audio Features	Stereo speakers, 2W x2, Nahimic Audio
  Ports & Slots
  HDMI Port	1x HDMI® 2.1, up to 8K/60Hz
  USB 3 Port	1x USB 3.2 Gen 1 1x USB 3.2 Gen 1 (Always On)
  USB Type-C / Thunderbolt Port	2x USB-C 3.2 Gen 2 (support data transfer, Power Delivery 135W and DisplayPort 1.4)
  Headphone & Microphone Port	1x Headphone/microphone combo jack (3.5mm)
  Network & Connectivity
  LAN	No Onboard Ethernet
  WiFi	Wi-Fi® 6E, 11ax 2x2
  Bluetooth	BT5.1
  Security
  Fingerprint Sensor	Touch Style, Integrated in Power Button
  Camera Privacy Shutter	E-shutter
  Security Chip	Firmware TPM 2.0
  Software
  Operating System	Windows 11 Home
  Power
  Battery Type	Integrated
  Battery Capacity	99.99Wh
  Adapter Type	230W Slim Tip (3-pin)
  Physical Specification
  Color	Onyx Grey
  Dimensions	357.7 x 260 x 16.9 mm (14.08 x 10.24 x 0.67 inches)
  Weight	Less than 2.23 kg (4.9 lbs)
  Warranty
  Warranty Details	2 years International Limited Warranty (Battery 1 year).

• Features: Backlit Keyboard, E-shutter
